Handheld Ultrasonic Nebulizer Portable Personal Cool Mist Inhaler Oil Humidifier

Features:

1.Compact and portable.
2.Quiet treatment and high efficiency.
3.Provide 2 airflow speeds

4.Eliminate the harmful substance

5.Take care of your respiratory tract, improve the immune response
6.Can use ordinary tap or distilled water with your physician-prescribed medication to create an effective high frequency mist.
7.Suitable for all ages, such as smokers, policeman,teachers, students, businessman, etc,
8.Aerosol therapy ensure you healthy with the illness of Cold, Acute pharyngitis, tonsillitis,chronic laryngitis, asthma, Bronchial Asthma and other respiratory illness,etc

Technical parameters :

Ultrasonic frequency: 2.4Mhz
Output voltage: DC12V
Input voltage: 110 ~ 220V
Droplet size: 0.5 ~ 5 micron
Cup capacity: 10ml
Vessel capacity: 25ml
Item weight: 159g / 5.6oz
Package size: 21.5*21*7.5cm / 8.5*8.3*3in
Package weight: 430g / 15.2oz

Usage:
1. Remove the top cover, take the cup and silicon gasket out.
2. Add 30ml purified water into the Water Chamber, the water level should be 3-5mm above the external silicon ring.
3. Fill the medicine cup half-full. put the cup into the chamber.
4. Re-install the top cover securely with the silicon gasket.
(Note: the best atomisation temperature in the chamber is 30℃/8℉)
Please use saline water or WARM(NOT boiling) water to sterilize the accessories.

Note:
1. Pease add purified water instead of running water into the water chamber.
2. The machine should be cleaned promptly after use.
3. Please check whether the machine is damaged, cracks, est. before and after using the product. If yes, please contact our customer service for replacements.

Troubleshooting:
1.If the machine doesn't work or red light flashes, check whether there's enough water in the water chamber, ensure that the Atomizing Cup can touch the water surface.
2. If completely no mist or small mist, check the following:
a. If the water tempreature is below 20℃/68℉, replace it with water at 40℃/104℉.
b. If the medicine liquid has a high concentration or small quantity, it needed to be diluted with normal saline before operate.
c. If the liquid for atomization contains large particles/impurity/precipitat/flatage/colloidal particles, the machine would not work.
d. Change a NEW cup, if no mist after few uses.
3.If the top cover does not fit, please ensure the silicon gasket been placed tightly.
4.For water leakage issue, please don't make the machine tilt.

Pakage included:

1 * Ultrasonic Nebulizer
2 * Mask (1 adult size, 1 children size)
5 * Medical cups
2 * Mouth pieces
1 * US/EU Plug AC adapter
1 * User Manual
